Wöhler A 450 L

5.000 ppm CO-Sensor
Order no. 4503
0%
    Wöhler A 450 L
    Wöhler A 450 L

    Wöhler A 450 L

    This is where Wöhler excels: A reasonably priced flue gas analyzer that offers all measurement and tuning functions. A small and lightweight flue gas analyzer enclosed in an eye-catching, sturdy housing. The Wöhler A 450 is a handheld device with user friendly touchscreen control, displays all measurement data on screen or connect and view on your smart devices.

    Large color touchscreen

    Displays up to 14 measurement readings

    Simple to use

    Switch on – read off – done

    Condensate protection

    Multistage filter technology incl. water stop filter

    App included

    Android or iOS

    Compact with a full range of functions

    The Wöhler A 450 L device is compact and lightweight by design and is guaranteed to be user friendly. The menu consists of icons similar to those known from smartphones, you simply tap an icon to open the individual menu items.

    Wöhler A 450 App

    You are able to transmit all measurement data to a mobile device (smart-phones, tablets by Android and iOS) via Wireless LAN. These devices can then display the measurements as numerical values or as a graph in the Wöhler A 450 app. The app gives technicians the option of reading measurements already taken and also the ability to take new measurements through the app. This proves to be beneficial when measuring at points with poor accessibility. The measurement data can be saved in different formats and sent to the customer by email.

    Sturdy and smart

    The Wöhler A 450 L is a well rounded tool that offers flue gas analysis, draft measurement, burner tuning guide, adjustment tasks on gas and oil systems and even solid fuel fireplaces.

    [Translate to International:] [Translate to United States:] Wöhler A 450 L Produktvergleich
    1) CO sensors 5,000 ppm or 100,000 ppm 24 months; CO sensor (H2 compensated) 10,000 ppm 48 months; excludes thermocouples, rechargeable battery and optional NO sensor.
    Product Comparison
     Wöhler
    A 450 L
    Wöhler
    A 450

    24 month sensor and analyzer warranty1)
    48 month sensor and analyzer warranty1)
    CO sensor5,000 ppm10,000 ppm
    O2 sensor0,0 ... 21,0 vol.-%0,0 ... 21,0 vol.-%
    Sensor replacement
    Burner adjustment assistant
    Setting tasks gas /oil systems
    CO-Sensor H2-kompensiert
    Wireless LAN, infrared, USB
    Rechargeable lithium ion batteryUp to 6 h operating timeUp to 6 h operating time
    NO-Sensoroptionaloptional
    Possible sensors33




    Large color touchscreen

    Displays up to 14 measurement readings

    Simple to use

    Switch on – read off – done

    Condensate protection

    Multistage filter technology incl. water stop filter

    App included

    Android or iOS

    Data transmission

    By USB, Wireless LAN or infrared

    Data Storage

    up to 1,000 customer records

    Rechargeable battery

    Operating time: more than 6 h with lithium ion power


    Additional Information
    Basic Set

    Scope of supply:
    Wöhler A 450 L with 5.000 ppm CO sensor
    WIFI, USB and IR interface
    probe 250 mm with 1.5 m hose
    USB charger with micro USB cable
    LI-ION battery 3,6 V / 2250 mAh
    25 cotton filters

    24 months warranty
