Wöhler VIS 200 Visual Inspection Camera

30 m (EN)
Order no. 5702

Wöhler VIS 200 Visual Inspection Camera

Wöhler's innovative VIS 250 service camera enables you to easily analyze damage in pipes of Ø 40 mm and larger – and no power outlet required. Compact by design and powered by a rechargeable battery, this complete camera set is supplied in a plastic case. The camera head features a powerful, integrated light to allow you to precisely analyze damage in waste water pipes (at least Ø 40 mm) and inspect downpipes as well as flue gas lines. Absolutely essential to analyze damage quickly!

Analyze damage and inspect:

  • Waste water pipes of Ø 40 mm and larger
  • Ventilation lines of Ø 40 mm and larger
  • Inspect hollow spaces; e.g. in front-wall installations
  • Flue gas lines up to approx. Ø 125 mm
[Translate to International:] [Translate to United States:] Kleiner Kamerakopf
Clear view, when space is tight

In addition to competently analyzing hidden defects in all types of buildings, the Wöhler VIS 250 provides you with transparent on-the-spot damage diagnostics.
Thanks to its user-friendly handling and instant start-up characteristics, you not only ensure your customers are satisfied but you can also feel relaxed about meeting the challenges ahead. The integrated video memory allows you to fully document your inspection work. The camera saves a video of the voyage of the camera head through the pipe. It passes even several 90° bends without problem. With a simple touch of a button a photo of a damaged spot can be made and stored.

[Translate to International:] [Translate to United States:] Bildschirm Inspektionskamera
Intelligent camera head guides and tracks

We have brought the localization of the damage to perfection so that it is easy to estimate the cost for the repair. The distance to the camera head is indicated in the display as well as the position. This helps very much in run of ducts. The display always shows where the top and the bottom of the duct are. The user also sees the exact angular momentum in which the camera head is pushed upwards or downwards. With the new Wöhler L 200 Locator it is even possible and economic to locate the camera head via radio.


Recommended Accessories
(Receiver)
Product ID 7430
Set
Product ID 4753
for camera head Ø 26mm
Product ID 3883
Ø20 cm
Product ID 3850
for camera head Ø 26 mm
Product ID 3827
for camera head Ø 26 mm
Product ID 3847
Product comparison



Wöhler
VIS 250

Wöhler
VIS 350

Wöhler
VIS 500

Wöhler
VIS 700 HD

Pan and tilt camera head 1.5"



interchangeable

interchangeable

interchangeable

Color camera head 1" dia

optional & interchangeable

optional & interchangeable

optional & interchangeable

HD-Touchscreen







Resolution

720 x 576p

720 x 576p

720 x 576p

1280 x 720p (HD)

Comment Function







Operation

Keyboard integrated in case

Keyboard integrated in case

Control pad on monitor unit

Joystick / Touchscreen

Anti slide stand

Optional anti slide mat

Optional anti slide mat

Integrated anti-slide pads

Integrated anti-slide pads

Adjustable focus







Object distance measurement function







Push rod distance counter

Voice recording





via optional headset

Display position and angle



Video & Photo recording

4 GB SD memory card

4 GB SD memory card

4 GB internal memory or optional USB-stick

8 GB internal memory or optional USB-stick

Home function



Transmitter in camera head

Wohler VIS app incl. report function





Operating time

2 x 2 hours

2 x 2 hours

6 hours

4 hours

different configurations possible





Removable camera rod






All properties
Crystal Clear Screen

Powerful TFT colour monitor for brilliant images

Store video footage and photos

On a 4 GB SD card (Wöhler VIS 250)

Transmitter integrated in camera head

makes it possible to precisely locate the camera head

Position indicator

Ensures the user knows where top and bottom are in the pipe at all times (Wöhler VIS 250)

Light-sensitive camera head

Waterproof

According to IP 68

Mobile solution

Fully equipped in a robust, plastic case

Electronic metering

Displayed on monitor

Operating time: 2 x 120 min

With 2 rechargeable batteries (optional)

Data exchange

Via mini USB cable (Wöhler VIS 250)

Additional Information
for visual inspection of water pipes, flues and ventilation lines fom 40 - 150 mm Ø

Scope of delivery:
Wöhler VIS 200 Service Camera
Wöhler color camera head Ø 26 mm V2
Wöhler TFT monitor 7" with 2 m cable
30 m push rod Ø 6 mm
digital meter counter
1 anti-slide-mat
1 NiMH-battery and charger
plastic case
